Provides extensive logic functions. The logic editor is integrated into the ETS. Up to 3000 logic gates are possible. Simulation for testing. User-defined function blocks can be created and saved. Requires 24 V DC auxiliary voltage or PoE alternatively.
Technical Data
| Maximum number of group objects : |
500 |
| Maximum number of group addresses : |
2000 |
| Maximum number of associations : |
2000 |
| Maximum number of logic elements : |
3000 |
| WebUI inputs and outputs : |
60 |
