SPECIFICATION
TYPE: Constant Voltage
DRIVER CURRENT (mA): N/A
DRIVER VOLTAGE (V): 12
DIMMABLE: Leading / Trailing Edge
ELECTRICAL CLASS: Class 2
SUPPLY VOLTAGE (V): 220-240V AC
SUPPLY FREQUENCY (Hz): 50
POWER FACTOR: 0.9
MIN. OUTPUT VOLTAGE (V DC): 0
MAX. OUTPUT VOLTAGE (V DC): 12
MIN. OUTPUT CURRENT (A): 0
MAX. OUTPUT CURRENT(A): 0.83
INRUSH CURRENT(A): 1.7A 40μsec
IP RATING: IP20
WORKING TEMPERATURE (ºC): -25 - +50
CONNECTION TYPE: Screw Terminals
LENGTH (mm): 101.5
WIDTH (mm): 51
HEIGHT (mm): 29.5
MIN. CIRCULAR APERTURE (mm/inch): 59mm / 2-5 / 16”
MAX. LED DISTANCE (m): 2
