Cable Design
| Conductor |
Stranded tinned copper wire (20awg) |
| Insulation |
LSZH FireFighter® |
| Core Identification |
see specification table |
| Core Stranding |
2 wires twisted to a pair. 1x2x20AWG |
| Outer Jacket |
LSZH FireFighter® |
| Colour |
Grey or White |
Characteristics
- Rated Voltage 600 V
- UV Stable acc. to UL 1581
- Flame retardant acc. to IEC 60332-1-2
- Fire Retardant acc. to IEC 60332-3-24 Cat.C
- Halogen Free acc. to IEC 60754-1
- Smoke Density acc. to IEC 61034
- Harmonised Standard B2ca-S1a, d0, a1
- Temperature Range -30°C to +70°C
Max. Installation Length* 100 m
*The information given is for guidance only; the installer should always check the system installation requirements to ensure the cable is fit for purpose.
