The MDT Dimming Actuator receives KNX/EIB telegrams and dimms/switches up to 4 independent electrical loads. Each output can be operated manually via a push button.
- Production in Germany, certified according to ISO 9001
- Comprehensive application
- Optimized for dimmable LED lights > 2W
- For HV- Halogen lights and NV- Halogen lights with transformer/EVG
- Operation in leading-edge or trailing-edge selectable
- Active power measurement
- Integrated diagnostic function with plain text message
- Overload-/short circuit- and temperature protection with message
- Time functions (switch-on/switch-off delay, staircase light function)
- Automatic time dependent dimming
- Softstart, global and individual dimming speed
- Day/Night function
- Parallel operation of 2 channels with 500W total power output
- Push Button for manual operation and indicator for each channel
- Separate L-/N connections for each channel
(different phases possible L1, L2, L3)
- 3 years warranty
