The world's first true presence detector! No unnecessary stay-ON times any more – no unnecessary electricity costs. Precision high-frequency measurement of the surrounding area provides 100 per-cent reliable detection. The True Presence detector reliably identifies whether persons are present or absent over an area of 64 m² – on the basis of the body's micro movements as well as human vital functions, such as breathing in and out, or shoulder movement. The new standard in building automation.
| General |
| Dimensions (L x W x H) |
32 x 103 x 103 mm |
| With motion detector |
Yes |
| Manufacturer's Warranty |
5 years |
| Settings via |
ETS software, Bluetooth, Bus |
| With remote control |
No |
| Type |
Presence detector |
| Application, place |
Indoors |
| Application, room |
classroom, lecture hall, one-person office, open-plan office, high-bay warehouse, production facilities, conference room / meeting room, hotel room, care room, duty room, recreation room, dining hall / staff restaurant, changing room, kitchenette, sports hall, reception / lobby, WC / washroom, warehouse, Indoors |
| Sensor technology |
| Technology, sensors |
High frequency, Light sensor, Temperature, Air humidity |
| Mounting height |
2,00 – 12,00 m |
| Mounting height max. |
12,00 m |
| Optimum mounting height |
2,8 m |
| Montagehöhe max. True Presence Erfassung |
4,00 m |
| HF-system
|
7,2 GHz
|
| Detection |
also through glass, wood and stud walls |
| Sneak-by guard |
Yes |
| Capability of masking out individual segments |
No |
| Electronic scalability |
Yes |
| Mechanical scalability |
No |
| Reach, radial |
Ø 15 m (177 m²) |
| Reach, tangential |
Ø 15 m (177 m²) |
| Reach, presence |
Ø 15 m (177 m²) |
| True Presence reach |
Ø 9 m (64 m²) |
| Detection angle |
360 ° |
| Angle of aperture |
160 ° |
| Twilight setting |
2 – 1000 lx |
| Time setting |
30 s – 1092 Min. |
| Basic light level function |
Yes |
| Main light adjustable |
0 - 100 % |
| Twilight setting TEACH |
Yes |
| Constant-lighting control |
Yes |
