For dimming dimmable LED, incandescent lamps, LV, HV halogen lamps and energy saving lamps. Dimming output: 400 W/VA per channel or 800 W/VA in parallel operation.
Function description
- 4-way universal dimmer actuator FIX2
- For dimming dimmable LED, incandescent lamps, LV, HV halogen lamps and energy saving lamps
- Also suitable for dimming of dimmable energy-saving lamps
- Also suitable for controlling fans
- LED switching status display for each channel
- Manual operation on device (even without bus connection)
- Dimming output: 400 W/VA per channel or 800 W/VA in parallel operation
- The dimming output can be upgraded by using additional dimmboosters "DMB 1 T KNX" - dimming output 300 W/VA for each dimmbooster. Output to a maximum of 2000 W/VA by using max. 4 boosters possible
- Automatic load detection (can be deactivated)
- For R, L and C loads
Technical data
|
| Operating voltage KNX |
Bus voltage, ≤4 mA |
| Operating voltage |
230 V AC 50 Hz |
| Frequency |
50 Hz |
| Stand-by consumption |
~1.5 W |
| Width |
8 modules |
| Installation type |
DIN rail |
| Type of connection |
Terminal screws | Bus connection: KNX bus terminal |
| Max. cable cross section |
Solid wire: 0.5 mm² (Ø 0.8) to 6 mm² | Stranded wire with end sleeve: 0.5 mm² to 4 mm² |
| Number of channels |
4 |
| Lamp types |
Incandescent, low-voltage and high-voltage halogen and dimmable energy saving lamps and LED |
| Incandescent/halogen lamp load |
400 W |
| LED lamp |
Trailing edge (RC-mode): 400 W |
| Energy saving lamps |
Trailing edge (RC-mode): 400 W |
| Switching capacity min. |
5 W |
| Max. cable length |
100 m |
| Ambient temperature |
-5°C ... 45°C |
| Type of protection |
IP 20 |
| Protection class |
II according to EN 60 669 |
