Description
The iONprime PB KNX touch sensors are available in aluminum, brass, and matt lacquered metal and plastic, and offer up to eight individually assignable control points. The iONprime CP 4 KNX room controller adds a visual dimension to the concept. With its 4-inch touch display, it enables intuitive control and display of up to 48 functions, from lighting and climate control to scene control.
iONprime CP 4 KNX Room Controller
- Room controller for temperature, humidity, proximity and brightness
- 4″ touch panel, 480 × 480 px
- Maximum of 6 pages with 48 functions
- Freely selectable background images
- KNX bus
iONprime PB KNX push button sensor
- Sensor for temperature, humidity, AQI, proximity, and brightness
- 1 base unit for different rockers
- Rockers in 3 variants (1-gang, 2-gang, 4-gang)
- Choice of 7 colors or materials
- RGB LEDs
Colors and materials
Notes on the power supply
- To ensure that the devices can be actively used and operated, the Promotion Set is
equipped with a USB- C connection for power supply - Please observe the following technical framework conditions to ensure reliable
operation: The promotion set works exclusively with a 5 Volt power supply. This is also printed accordingly on the promotion set. - It can be easily operated via USB-A to USBC cable.
- When using USB-C on USB-C or other cables, the following must be considered: The power source used must not support Power Delivery (PD) under any circumstances.
- Modern chargers / power supplies support this function and are therefore not
compatible with the Promotion Set. With Power Delivery, a different voltage is output depending on the type of device connected. - This does not work with the Promotion Set, as device identification is not possible
compared to a smartphone or tablet. Power sources with PD can be recognized by
different voltage specifications: For example USB-C: 5.0V / 9.0V / 12.0V - Many modern Notebook USB-C ports also support PD power supply and their power adapters cannot be used either, as they also support PD.
Range: ION Prime
