8-way high-performance switching actuator FIX2 with a 25 A Switching capacity and Bistable relays. Manual control and LED switching status display for each channel.
Function description
- 8-way high-performance switching actuator FIX2
- Bistable relays
- Switching capacity 25 A
- LED switching status display for each channel
- Manual operation on device
- Switching functions: On/Off, pulse, On/Off delay, staircase light with warning
- Logical links: e.g. lock, AND, release, OR
Technical data
|
| Operating voltage KNX |
<10 mA |
| Installation type |
DIN rail |
| Width |
8 modules |
| Type of connection |
Terminal screws | Bus connection: KNX bus terminal |
| Max. cable cross section |
Solid wire: 0.5 mm² (Ø 0.8) to 6 mm² | Stranded wire with end sleeve: 0.5 mm² to 4 mm² |
| Number of channels |
8 |
| Type of contact |
25 A, 16 A |
| Opening width |
< 3 mm |
| Resistive load |
4800 W |
| Energy saving lamps |
410 W |
| LED lamp < 2 W |
75 W |
| LED lamp 2-8 W |
850 W |
| LED lamp > 8 W |
850 W |
| Inrush current |
max. 1200 A / 200 µs |
| Switching of various phases |
Possible |
| C load |
Yes |
| Type |
Module FIX2 |
| Ambient temperature |
-5°C ... 45°C |
| Type of protection |
IP 20 |
| Protection class |
II according to EN 60 669 |
