| Connection technology |
Push-in CAGE CLAMP® |
| Actuation type |
Push-in
Operating tool
|
| Connectable conductor materials |
Copper |
| Nominal cross-section |
1.5 mm² |
| Solid conductor |
0.25 … 2.5 mm² / 22 … 14 AWG |
| Solid conductor; push-in termination |
0.75 … 2.5 mm² / 18 … 14 AWG |
| Fine-stranded conductor |
0.25 … 2.5 mm² / 22 … 14 AWG |
| Fine-stranded conductor; with insulated ferrule |
0.25 … 1.5 mm² / 22 … 16 AWG |
| Fine-stranded conductor; with ferrule; push-in termination |
0.75 … 1.5 mm² / 18 … 16 AWG |
| Note (conductor cross-section) |
Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination. |
| Strip length |
9 … 11 mm / 0.35 … 0.43 inch |
| Wiring direction |
Front-entry wiring |
